低溫噴霧干燥機設備的工藝要求

低溫噴霧干燥機是一種能夠同時完成干燥和造粒的設備。 根據工藝要求，可以調整噴孔的壓力、流量和尺寸，以一定的尺寸比例獲得所需的球形顆粒。

Low temperature spray dryer is a device that can dry and granulate at the same time. According to the process requirements, the pressure, flow rate and size of the nozzle can be adjusted to obtain the required spherical particles with a certain size ratio.

低溫噴霧干燥機可采用全自動或手動監控兩種操作模式，便于實驗過程的操作和監控，特別是實現了低溫條件下( 50℃)物料的瞬時干燥，為酶制劑、活性細菌、高糖中藥天然產物提取物、耐熱高分子材料、受熱物料等生物制品等熱敏性物料提供了極其方便、安全的干燥方法

Low temperature spray dryer can be operated by two modes of automatic or manual monitoring to facilitate operation and monitoring of the experimental process, especially under low temperature conditions. Instantaneous drying of materials at 50 ℃ provides an extremely convenient and safe drying method for enzyme preparations, active bacteria, extracts of natural products of high sugar traditional Chinese medicine, heat-resistant polymer materials, heated materials and other biological products and other heat sensitive materials

低溫噴霧干燥機的性能特點

Performance characteristics of low temperature spray dryer

干燥速度快，霧化后料液的表面積大大增加，95 % - 98 %的水可以在熱風流中瞬間蒸發，干燥時間只需要十幾秒到幾十秒，特別適合熱敏材料的干燥。所有產品均為球形顆粒，粒徑均勻，流動性好，溶解性好，純度高，質量好。應用范圍廣，根據材料的特點，熱風可用于干燥或冷風造粒，對材料適應性強。操作簡單穩定，控制方便，易于實現自動化操作。

The drying speed is fast, the surface area of the material liquid is greatly increased after atomization, 95% - 98% of the water can evaporate instantly in the hot air flow, and the drying time only takes ten seconds to dozens of seconds, which is especially suitable for the drying of thermal sensitive materials. All products are spherical particles with uniform particle size, good fluidity, good solubility, high purity and good quality. According to the characteristics of materials, hot air can be used for drying or cold air granulation, which has strong adaptability to materials. Simple and stable operation, convenient control, easy to realize automatic operation.

在噴霧干燥機實驗中，熱風溫度是很重要的一個參數，其是指干燥時所用熱風進入塔內的溫度，一般是越高越好，因為這樣其經濟性就會(huì )提高了。不過，熱風溫度也不能無限高，因為如果過高的話，那么則會(huì )帶來不良影響，比如使得干燥后的成品的質量變差。所以說，想要提高其溫度，那么應先確保能夠保證產品質量，然后再來適當提高。

In the experiment of spray dryer, hot air temperature is a very important parameter. It refers to the temperature of the hot air entering the tower when drying, generally the higher it is, the better the economy will be. However, the hot air temperature can not be infinitely high, because if it is too high, it will bring adverse effects, such as making the quality of the dried product worse. Therefore, if we want to increase the temperature, we should first ensure that the product quality can be guaranteed, and then properly improve it.

噴霧干燥機的熱風溫度，其主要是會(huì )影響到干燥成品的松密度，以及干燥室的蒸發強度。如果是對食品進行干燥，那么其溫度一般不能超過177℃，以免產品出現空心顆粒。但如果是非熱敏性物料，那么應盡量采用高溫熱風，以便可以來提高蒸發強度。

The hot air temperature of the spray dryer will mainly affect the loose density of the dried products and the evaporation intensity of the drying chamber. If the food is dried, the temperature should not exceed 177 ℃ to avoid hollow particles. But if it is non heat sensitive material, high temperature hot air should be used as far as possible to improve the evaporation intensity.
